Ball Valves
Overview
Ball valves deliver fast, quarter-turn operation and bubble-tight shut-off. A precision-finished ball rotates within resilient or metal seats, offering low torque, minimal maintenance and dependable performance for isolation duty across demanding industries.
Key Features
- Quarter-turn, bubble-tight shut-off
- Floating and trunnion-mounted designs
- Single, two and three-piece constructions
- Soft (PTFE) or metal-seated trims
- Fire-safe and anti-static options
Applications
Oil & gas Chemical Petrochemical Water treatment Gas distribution
Technical Data
| Size Range | 1/2" – 36" (DN15 – DN900) |
|---|---|
| Pressure Class | Class 150 – 2500 / PN16 – PN450 |
| Body Materials | WCB, CF8 (SS304), CF8M (SS316), forged A105 / F304 / F316 |
| Trim / Internals | SS316 ball & stem, PTFE / RPTFE / Metal seats |
| End Connections | Flanged, Screwed, Socket-weld, Butt-weld, Wafer |
| Operation | Lever, Gear, Electric / Pneumatic actuator |
| Standards | API 6D / API 608 / BS EN ISO 17292, IBR approved |
Full datasheet available on request
Types & Configurations
Available in the following designs — each can be tailored to your specification.
